Avatar-ET 3.4M (F5J) (#0092)

Avatar-ET 3.4M is Light weight electro-glider F5J class. It’s clean low drag design provides excellent air penetration with wide range of speed and flying weight ~1570 g (~55 oz.) makes it an ultimate thermal electro-glider. Avatar-ET wing is equipped with internally hinged Ailerons and Flaps – this feature not only reduce building time but also makes the wing stronger.
The Fuselage pod and vertical stabilizer are made from pre-painted, molded, composite materials (epoxy/glass-carbon-fiber).
The Fuselage pod features removable Canopy for easy access to radio and drive gear and is 2.4GHz friendly.
Strong tapered tail boom is made of carbon-glass-fiber composite.
The wing cores are precision cut from special high-density white polystyrene foam and for superb strength wings have molded in carbon/glass composite spars.
The black poplar veneer is bonded to the foam with aircraft industry grade epoxy in high pressure mold for perfect airfoil fidelity and warp-free wing. Our original 3-segments wing design is very strong and convenient, internally hinged ailerons and flaps are minimizing the building time. The horizontal stabilizer with pre-hinged elevator and rudder are made from selected balsa wood and fully laminated. The removable horizontal stabilizer and 3-segment wing allows easy storage and transport flexibility.

Kit contains:
model, plans, step by step instructions, all necessary hardware and glider name wing sticker.
NOTE: Wing version with Aileron and Spoilers is also available.

There’s a 3-8 day shipment delay for 2,5M+ models.

$ 417.84

Dostępne:

In stock

Description

Wing span 3400 mm / 133.85 in.
Length ~1500 mm / ~59.05 in.
Wing area 55.44 dm² / 859.32 sq.in.
Wing airfoil SD7080-modified
Glider weight ~950 g / ~33.33 oz.
Weight in flight ~1570 g /~ 55 oz.

Additional information

Weight 2 kg
